TruTool C 160

Ideal view for precise cutting

The cost-effective model without chip clipper is particularly well-suited to cutting tasks without chip clipping during the cutting process – for example, trimming straight sheets to length or cutting curves. A clear view of the workpiece enables you to cut accurately. The TruTool C 160 cuts sheet thicknesses of up to 0.06 inches in mild steel and 0.047 inches in stainless steel

Category: Platesaks

Product description

Machine without chip clipper

For applications where chip clipping is not necessary during the cutting process.

Ideal for trimming to length

Well-suited to straight, distortion-free cuts and C-L-U profiles.

Machine without chip clipper

For applications where chip clipping is not necessary during the cutting process.

Ideal for trimming to length

Well-suited to straight, distortion-free cuts and C-L-U profiles.

Particularly lightweight and ergonomic

The machine’s light weight and well-engineered ergonomics mean low fatigue levels during operation.

For any application

For perfect results, you can choose between four different cutters.

TruTool C160 without chip clipper, dimensional drawing

TruTool C 160, dimensional drawing

CR cutter, for optimal processing of stainless steel

Outstanding service life

We offer four different cutters to suit particular applications: the CR cutter is ideal for processing stainless steel. The curve cutter cuts with excellent contouring. There are two different cutters for straight cuts: one cutter for processing thin sheets of up to 0.04 inches and one for use on sheet thicknesses of 0.04 – 0.06 inches.

Technical data

	TruTool C 160
Maximum sheet thicknesses
Maximum sheet thickness, steel up to 400 N/mm²	1.6 mm
Maximum sheet thickness, steel up to 600 N/mm²	1.2 mm
Maximum sheet thickness, aluminum up to 250 N/mm²	2 mm
Radii
Smallest radius	90 mm
General
Working Speed	6 m/min - 10 m/min
Stroke rate with nominal load	3800 RPM
Starting hole diameter	15 mm
Nominal power consumption	350 W
